Application :

• Corona Treatment Machine
• Extrusion Coating Machine
• Thermal Lamination Machine
• Heat & Press Lamination Machine
• Cutting Sealing Machine
• Holography Machine
• Foil Processing Machine
• Other Coating Lamination Machine

CAPACITY :
Diameter up to 750mm, Length up to 6000mm including journals, Hardness form 20 Shore A to 100 Shore A and 70 Shore D. Run out (eccentricity) of rubber surface 0.02-0.05 mm depending on hardness and type of rubber.

MACHINERY :
Rubber Processing (Bale cutting, Aoutomatic Batch Weighing System, Dispersion Kneader Mixing mill) Roll Covering (Automatic Strip Binding), Valcanising, Grindign etc.

TESTING :
Surface Plate of 2 m x 1 m for testing (eccentricity, parallelism), Dimensional accuracy Vernier (3mtr., 1mtr., 300mm) Micrometer (0-25mm, 25-50mm, 50-100mm, 100-400mm with 0.001 resolution), Dial Guages, Hardness tester etc. Testing of compounds for rheological properties, compression set and abrasion are done at reputed laboratories.
